Chapter 4 Installation and Wiring
PAGE 4-19
Offset (Standard)
● OA-3S3-x-50-50 (x = stroke in inches: 2 std., 3 or 4 optional)
Tool Type
Standard Stroke
[inches]
Female Input
Square Drive
Male Output
Square Drive
Mounting
Screw Size
CFT-801RS3-O 2.00 1/2” 1/2” (4) M8x1.0
● SA-OS3-x-62-62 (x = stroke in inches: 2 std., 3 or 4 optional)
Spindle Type
Standard Stroke
[inches]
Female Input
Square Drive
Male Output
Square Drive
Mounting
Screw Size
CFT-202RS3-O 2.00 5/8” 5/8” (4) M8x1.25
