 SEQUENCE SELECT BIT 0~4: Sequence Select Bit (Binary coded) Used when set as Multi System
 PARAMETER SELECT BIT 0~4: Parameter Select Bit (Binary coded) Used when set as Single
System.
These 5 inputs form a binary code which is capable of selecting up to 32 different sequences (Master)
or parameters.
PAR
/ SEQ
SELECT BIT 4
Pin No. ：
：：
： 12
PAR / SEQ
SELECT BIT 3
Pin No. ：
：：
： 11
PAR / SEQ
SELECT BIT 2
Pin No. ：
：：
： 10
PAR / SEQ
SELECT BIT 1
Pin No. ：
：：
： 9
PAR / SEQ
SELECT BIT 0
Pin No. ：
：：
： 8
Parameter
(Sequence)
No.
OFF OFF OFF OFF OFF
1
OFF OFF OFF OFF ON
2
OFF OFF OFF ON OFF
3
OFF OFF OFF ON ON
4
OFF OFF ON OFF OFF
5
OFF OFF ON OFF ON
6
OFF OFF ON ON OFF
7
OFF OFF ON ON ON
8
OFF ON OFF OFF OFF
9
OFF ON OFF OFF ON
10
OFF ON OFF ON OFF
11
OFF ON OFF ON ON
12
OFF ON ON OFF OFF
13
OFF ON ON OFF ON
14
OFF ON ON ON OFF
15
OFF ON ON ON ON
16
ON OFF OFF OFF OFF
17
ON OFF OFF OFF ON
18
ON OFF OFF ON OFF
19
ON OFF OFF ON ON
20
ON OFF ON OFF OFF
21
ON OFF ON OFF ON
22
ON OFF ON ON OFF
23
ON OFF ON ON ON
24
ON ON OFF OFF OFF
25
ON ON OFF OFF ON
26
ON ON OFF ON OFF
27
ON ON OFF ON ON
28
ON ON ON OFF OFF
29
ON ON ON OFF ON
30
ON ON ON ON OFF
31
ON ON ON ON ON
32
