FLIR T Series

To Next Page

To Previous Page

Pin configuration

for video

connector

10763503;a1

ConfigurationPin

Audio right1

Ground2

Video out3

Audio left4

Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010 115

24 – Pin configurations
