Pin configuration

for USB-A

connector

10763303;a1

ConfigurationPin

+5 V (in)1

USB –2

USB +3

Ground4

116 Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010

24 – Pin configurations
