FLIR T Series User Manual

Zoom button
■
The zoom button has the following functions on live images:
■
Push to enter the zoom state.
■
Use the joystick to zoom into or out of an image.
■
Push the zoom button once again to reset to 1× zoom factor.
■
Push the A/M button, the joystick, or the Preview/Save button to
confirm the zoom factor and leave the zoom state.
■
The zoom button has the following functions on still images:
■
Zooming:
■
Push to enter the zoom state.
■
Use the joystick to zoom into or out of an image.
■
Push the zoom button once again to reset to 1× zoom factor.
■
Push the A/M button or the Preview/Save button to confirm the
zoom factor and leave the zoom state.
■
Panning:
■
Push to enter the zoom state.
■
Push the joystick to enter the pan state.
■
Use the joystick to pan over an image.
■
Push the joystick to confirm the pan position and leave the pan
state.
3
Stylus pen
Note: Push the stylus pen firmly into its holder when not in use.
4
Camera button
The camera button has the following functions:
■
On live images: Switch between the infrared camera and the digital
camera (IR > DC).
■
On live fusion images: Switch between fusion and infrared imagery.
Switching between fusion and infrared imagery enables you to accurately
focus the infrared image (IR > DC > fusion).
You can set up the behavior of this button under Setup.
5
Joystick
The joystick has the following functions:
■
In live infrared manual mode, and in still infrared mode:
■
Push up/down to adjust the level.
■
Push left/right to adjust the span.
■
In menus, in dialog boxes, and in the image archive:
■
Push up/down or left/right to navigate.
■
Push to confirm choices.
6
12 Publ. No. 1558792 Rev. a460 – ENGLISH (EN) – July 1, 2010
9 – Camera parts
