Fortinet FortiGate Series

System Status Viewing the system dashboard
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 121
http://docs.fortinet.com/ • Feedback
Figure 40: Top sessions bar graph showing destination IP addresses
Select Details to view the current sessions list, a list of all sessions currently processed by
the FortiGate unit. See “Viewing the current sessions list” on page 122.
To view detailed information about the sessions represented by a bar in the chart, click on
the bar.
To change the information displayed on the Top Sessions widget
1 Selecting edit icon to change the information displayed by the Top Sessions widget:
2 Change the Top Sessions settings as required:
Report By
Number of
active
sessions
Number of
current sessions
Last updated
View the session list
Customize the Top Sessions Display
Detach
Refresh
Close
