Fortinet FortiGate Series Administration Guide

Viewing application, policy, and DLP archive usage data System Status
FortiGate Version 4.0 MR1 Administration Guide
140 01-410-89802-20090903
http://docs.fortinet.com/ • Feedback
Figure 53: Top Policy Usage table display
To configure the Top Policy Usage module
1 Go to System > Status > Usage.
2 Select the Edit icon in the Top Policy Usage module title bar.
3 Enter the following information and select OK.
Figure 54: Configuring the Top Policy Usage module
Reset Reset all counts to zero.
Edit Configure module settings.
Refresh Update displayed information.
Close Close the module.
Policy ID The firewall policy identifier.
Total Bytes or
Total Packets
The cumulative traffic volume for the firewall policy in bytes or packets,
depending on the Sort Criteria setting.
Sort Criteria Select whether to sort the policies by number of Bytes or number of
Packets.
VDOM Select the VDOM to monitor or select Global. This is available for
global administrators only. VDOM administrators see only their only
VDOM.
Display Format Select Chart or Table display.
Top Entries To Show Select whether to display top 5, 10, 15, or 20 applications.
Refresh Interval Select display update interval in seconds. Range 10 to 240 seconds.
Select 0 to disable updating. You can also update using the Refresh
icon in the module header.
Reset
Edit
Refresh
Close
