Fortinet FortiGate Series Administration Guide

System Admin Customizable web-based manager
FortiGate Version 4.0 MR1 Administration Guide
01-410-89802-20090903 295
http://docs.fortinet.com/ • Feedback
2 Select and rename the default name to Custom Log Report Tab1 (see Figure 141).
3 Press Enter to save your change.
4 Repeat steps 1 to 3 to create a second tab called Custom Log Report Tab2.
5 To save your customized layout, select Save in the GUI layout dialog box (see
Figure 138).
Figure 140: Create New tab
Figure 141: Creating tabs in page layout
To modify the configuration of the current page
1 Select the required tab, then select Edit Layout.
The Edit this tab dialog box appears (see Figure 142). You may configure the page
layout to display only one widget (Full page), a page layout with one column that
displays up to 8 widgets (1 column), or a page layout with two columns (2 columns)
that displays up to 8 widgets.
2 For the Custom Log Report Tab1, select 2 columns.
3 To save your modified configuration, select Save in the Edit this tab dialog box.
Create New tab item icon
Creation of tab
Custom Log Report Tab1
Creation of tab Custom Log Report Tab2
