TX100 S3 Core Edition Upgrade and Maintenance Manual 161
Accessible drives
Figure 99: Connecting the power cable to the backup drive
Ê Connect the power adapter cable to power cable connector P7 (1).
Ê Connect the other end of the power adapter cable to the backup drive (2).
/
