TX100 S3 Core Edition Upgrade and Maintenance Manual 227
Cabling
Figure 149: Disconnecting/reconnecting the power cable on the backup drive
Ê Disconnect the defective power cable (connector P7) from the power
adapter cable.
I It is not necessary to remove the power adapter cable from the
backup drive.
Ê Connect the new power cable (connector P7) to the power adapter cable.
