6. Radar
6-24
6.25 FAR-2107 Radar Series and NavNet 3D
The FAR-2107 radar series (program no. 02.50 and after, C specification) can be con-
nected to your NavNet 3D, and some functions can be controlled from the NavNet 3D.
The table shown below shows which features can be controlled from the NavNet 3D.
Note that you should turn off Guard Polygon at the radar to control the radar from the
NavNet 3D.
Function
Controllable from
NavNet
Remarks
AIS data (LAN) No
AIS data (NMEA 0183) No
AIS data display Yes
ARPA acquisition,
cancellation
Yes
Auto Gain No
Auto Rain No
Auto Sea Yes Value of Auto Sea is “0”.
Automatic ARPA target ac-
quisition
No
Dual range mode No
Gain Yes Manual only
Installation setting (tuning,
antenna rotation speed,
etc.)
No
Manual ARPA target acqui-
sition, cancel
Yes Max. no. of targets is 100.
Position, time data Yes Shared via LAN
Range scale Yes 0.0625, 1, 2, 4, 8, 16, 32, 36, 64,
72, 120 not available with IMO
specification. 72 nm not available
with C specification.
Selection of range unit No Fixed at “NM”
Source selection, picture
display
Yes
TX/STBY Yes
Watchman No
