Furuno MFD12 User Manual

13. How to Adjust Settings
13-7
13.2 Data Boxes
Section 1.14 shows how to select the data to show in the data boxes. This section
shows you set the boxes from the [DataBox] menu.
13.2.1 How to Set the Data Boxes
1. Press the MENU key to open the menu.
2. Open the [DataBox] menu.
3. Use the RotoKey to select [Data Box] 1-4 or [Cursor Data Box] then push the Ro-
toKey. For example, select [Data Box 1].
1 2 3
4
Data box locationsData box options
Cursor data box
Data boxes 1-4

Furuno MFD12 Specifications

General

Display Size	12.1 inches
Brightness	1000 cd/m²
Touchscreen	Yes
Power Supply	12-24 V DC
Operating Temperature Range	-15°C to +55°C
Input Voltage	12-24 V DC
Display Type	LCD
Resolution	800 x 600
Storage Temperature	-20°C to +70°C
