3. 3D Display, Overlays
3-3
3.1.2 Underwater Display
The underwater display provides a look into the water from above the water. This dis-
play is available between 7 yards and 1.003 nm.
To activate the underwater display, use the RotoKey to select the [3D] and [Under-
water] soft controls. You can rotate the picture with W and X on the ScrollingPad.
Underwater display
Your
ship
Land
Depth
contour
Depth to
bottom
Under-
water
