Furuno MFD12 - How to Set ACCU-FISH

7. Fish Finder
7-18
7.12.1 How to Set ACCU-FISH
1. Press the MENU key to open the menu.
2. Open the [Fish Finder-DFF/FCV] menu.
3. Use the RotoKey to select [Measurement].
4. Use the RotoKey to select [Accu Fish] to activate (Accu Fish) or deactivate (Off)
ACCU-FISH.
5. Select [Fish Info].
6. Select [Fish Size] or [Depth].
7. Select [Info Size].
8. Select the size for fish info (fish size or depth).
9. Select [Fish Symbols].
10. Select [Solid], [Striped] or [Off] (turn off fish symbol).
11. Press the MENU key several times to close the menu.
Fish size Solid Striped
Large fish symbol(more than 51 cm
(20.08 inch))
Small fish symbol(10 to 50 cm (3.93
to 19.69 inch))
15
60
60
15
Solid
(Small)
Solid
(Large)
Striped
(Small)
Striped
(Large)
Fish size or depth is displayed in red.
