Furuno MFD12 - Weather Icons

11. Sirius Weather Receiver
11-2
11.2 Weather Icons
The table below shows the weather icons that appear on the Sirius Satellite Weather
display. You can show or hide these icons from the [Weather] menu.
NOWRAD
(USA RADAR)
Pink
Icon Meaning
Pink Storm cast
Lightning
Buoy: Red
CMAN station: Grey
Airplane: White
Surface
observation
stations
Wind
Grey Cities
Dark blue
Waves
Green-red
CANRAD
(Canadian
radar)
Red-blue
Sea surface
temperature
Storm tracks
etc.
For details, see page 7-6.
Surface
pressure
Color
Dark yellow (recorded in last 0-5 min.)
Medium yellow (recorded in last 5-10 min.)
Light yellow (recorded in last 10-15 min.)
Green (Rain)
Blues (Snow)
Pinks (Mixture)
Grey (Historical)
Red (Current)
Orange (Forecast)
Buoy or
CMAN sta.
