14. Maintenance, Troubleshooting
14-2
14.2 Fuses
The MFD has a fuse that protects the MFD from high electric current and equipment
fault. If you cannot turn on the power, check the fuse to see if it has blown. Find the
reason for the blown fuse before you replace the fuse. If the fuse blows again after the
replacement, contact your dealer for information. A wrong fuse can damage the equip-
ment.
Fuse information
14.3 The Magnetron
When the life of the magnetron is reached, the targets do not appear on the radar dis-
play. If long-range performance appears to have decreased, contact a FURUNO
agent or dealer about replacement of the magnetron.
Magnetron information
Name Type Code No. Remarks
Fuse FGB0-A 125V 5A PBF 000-155-853-10 For MFD8, 24V
Fuse FGB0 125V 10A PBF 000-155-826-10 For MFD8, 12V
Fuse FGB0 125V 10A PBF 000-155-826-10 For MFD12, 24V
Fuse FGB0 125V 20A PBF 000-155-780-10 For MFD12, 12V
Radar Sensor Magnetron Code No.
DRS2D E3590 000-164-574-10
DRS4D E3571 000-146-867-00
DRS4A MAF1421B 000-158-786-10
DRS6A MAF1422B 000-158-788-10
DRS12A E3566 000-164-418-10
DRS25A MG5436(E2V) 000-140-762-10
WARNING
Use the proper fuse.
A wrong fuse can damage the equipment
and cause fire.
