1. System Introduction
1-4
5 RotoKey • Rotate to display soft controls, the quantity
(basic, standard, full or custom) of which you
select from the menu, or select the menu item.
• Short-push to display soft controls, the quanti-
ty (basic, standard, full or custom) of which is
indicated on the menu, or validate a selection.
• Long-push to display all available soft controls
for the current mode.
Scrollwheel.
Turn to dis-
play soft con-
trols or select
item. Push to
validate se-
lection.
6 DISP Select a display. -
7 CANCEL Undo or cancel last operation. -
8POINTS/
ROUTE
POINTS: Save the cursor position as a point.
ROUTE: Activate the route building tool.
-
9 GO TO/LIST GO TO: Set the cursor position as the destina-
tion.
LIST: Open the Points menu.
-
10 CursorPad • Pad: Move the cursor.
• Functions like the "left-click" button on a
PC mouse. This button the name “left-click”
button in this manual.
• Move the
cursor.
• Left
mouse
button
11
(right-click
button)
Show a pop-up menu. This button has the name
“right-click” button in this manual.
Right mouse
button
12 DATA/VOL DATA: Show and hide the data boxes.
VOL: Change audio level. If you have the Sirius
weather receiver, the Sirius satellite radio screen
appears.
-
13 MENU Open and close the menu. -
14 GAIN/TX GAIN: Adjust the gain for the radar and the fish
finder.
TX: Change between stand-by and transmit on
the radar and fish finder.
-
15 RANGE OUT,
IN
• Select range on the chart, radar and fish
finder.
• Zoom in and zoom out the Axis IP camera
image.
-
16 ScrollingPad • Pad: Scroll the chart, radar picture and AXIS
IP camera image.
• SHIP/3D button: Short-push to put your ves-
sel at the center of the screen. Long-push to
change between the 3D and 2D displays alter-
nately.
-
17 Power lamp Lights when the power is applied to the system. -
No. Label Function
Mouse
operation
