4 Connecting the modules → Q.bloxx A106: Connecting sensors and I/O
4.13.6 Digital input and output
On each connecting plug two contacts are available for an input
or output. You can use the appropriate function depending on the
wiring.
Fig. 4-51 A106, Digital Input and Output.
The digital input is active (high level) when the applied signal
voltage lies above the threshold of 10 V.
Input Output
D
in
D
out
1, 2
+V
0V
1, 2
