Gantner Q Series User Manual

Q.series
Gantner Instruments GmbH
65
4 Connecting the modules → Q.bloxx A107: Connecting sensors
4.14 Q.bloxx A107: Connecting sensors
The Q.bloxx Module A 107 has four electrically isolated analog
inputs. The pin assignment of the two connector strips is identical
and the connection terminals have numbers for identifying the
connections. You will find the associated figures in each case at
the same place in the circuit diagrams, for example each of the
figures quoted in the second place belong to one possible connec-
tion method.
GND identifies the measurement ground. The four inputs (UF to
GND) are el
ectrically isolated in the module one to the other and
to the (module) supply voltage.
Fig. 4-52 Pin assignment for Q.bloxx Module A107.
Tip
Further information on transducers and sensors can also be
found in Chapter 6 ff. page 135.
4.14.1 Voltage
You can measure voltages of up to 10 V.
4, 9
3, 8
1, 6 (+)
5, 10 (GND)
U
2, 7 (+)
5, 10 (GND)
I
2, 7 (+)
5, 10 (GND)
1, 6 (+)
5, 10 (GND)
2, 7
1, 6
2, 7
1, 6
4, 9
2, 7
3, 8
3, 7 (–)
2, 6 (+)
1UF
2A
In
1
3A
In
2
4A
In
3
5GND
6UF
7A
In
1
8A
In
2
9A
In
3
10 GND
1UF
2A
In
1
3A
In
2
4A
In
3
5GND
6UF
7A
In
1
8A
In
2
9A
In
3
10 GND
10110 1Plug 1Plug 2
requires Q.bloxx
Terminal CJC
