Q.series
Gantner Instruments GmbH
105
5 Configuration → Using test.commander
5.2.2 test.commander and the serial (service) interface
test.commander uses the serial interface exclusively as a service
interface for the Q.gate Test Controller or Q.pac Test Controller
to set the IP address for Ethernet. Setting connected modules is
not possible via this interface.
Procedure 1. Connecting the PC and module via the interface.
Use the supplied cable with the jack plug for the connection
to the
PC interface; refer also to Section 4.4.4, page 35.
2. Start the program
1
.
3. Using the menu Utilities, c
all the menu item Controller
Setup Wizard.
4. In the program window using the menu Options > Commu-
nication Settings, specify
the setting RS232 direct con-
nection as the interface type as
well as the PC COM port
used.
5. Call the program for the settings via the menu Utilities >
Contro
ller serial terminal.
The program searches the above specified interface for the
Test Con
troller and presents you with a dialog in which you
can read out the existing settings (Read) or set a new Ether-
net address (and subnet mask) or DHCP (Wri
te).
1)
If you are not initially creating a project, close the starting dialog with Cancel.
