Gantner Q Series User Manual

Q.series
Gantner Instruments GmbH
19
3 Introduction
Depending on the operating mode of the modules, transmission
rates of 1 kHz with up to 128 variables (transferred values with
fo
ur byte resolution, real variables) are possible over Ethernet.
3.3.2 Operating the modules via Q.pac
The Q.pac Test Controller is a programmable module with its own
128 Mbyte flash data memory and in addition it
offers a graphi-
cally programmable PAC function. Optionally, EtherCAT is avail-
able as an additional inte
rface with a data rate of up to 10 kHz.
You can connect up to 16 modules to e
ach of the four serial inter-
faces (UARTs) of the Q.pac Test Controller (Fig. 3-3, page 20).
When using Ethernet, with Q.pac you can realize up to
16 vari-
ables (transferred values with four-byte resolution, real variable)
at a sample rate o
f 10 kHz and with EtherCAT even 256 variables
are possible at the sa
me sample rate:
UART data throughput at 24 MBaud
Sample rate 1 kHz
Sample rate 10 kHz
Sample rate 100 kHz
200 real variables
20 real variables
2 real variables
Ethernet data throughput (transmission rate with block transfer)
128 real variables (1 kHz)
16 real variables (10 kHz)
Ethernet data throughput (transmission rate with online transfer) 64 real variables (300 Hz)
Interfaces
Ethernet, USB, RS-232,
2 UARTs
Max. number of slaves (Q.bloxx) 32
UART data throughput at 24 MBaud
Sample rate 1 kHz
Sample rate 10 kHz
Sample rate 100 kHz
200 real variables
20 real variables
2 real variables
Ethernet data throughput (transmission rate with block transfer)
128 real variables (1 kHz)
16 real variables (10 kHz)
Ethernet data throughput (transmission rate with online transfer) 128 real variables (300 Hz)
EtherCAT data throughput (transmission rate) 256 real variables (10 kHz)
Interfaces
Ethernet, EtherCAT, USB,
RS-232, 4 UARTs
Max. number of slaves (Q.bloxx) 64
