4 Connecting the modules → Q.bloxx A116: Connecting sensors
Fig. 4-71 Terminal assignment for the Q.bloxx Connection Terminal
CT A116.
Assignment of the cable cores for a cable termination with free
ends Cable A116:
U
SIG+
(B7)
U
SEN+
(B8)
U
EXC+
(A7)
A
IN2
U
SIG-
(B9)
U
SEN-
(A9)
Q.bloxx 116 Junction Box
2
1357
468
U
EXC-
(A8)
U
EXC+
(A3)
U
SEN+
(B4)
U
SIG+
(B3)
A
IN1
A
IN3
A
IN5
A
IN7
A
IN4
A
IN6
A
IN8
U
EXC-
(A4)
U
SEN-
(A5)
U
SIG-
(B5)
Input/
cable
bundle
Pairing Cable color
Sensor connec-
tion
Socket connection
1
Pair 1
Light brown
U
Exc+
A3
Light brown/red
U
Exc–
A4
Pair 2
Light green
U
Sen+
B4
Light green/black
U
Sen–
A5
Pair 3
White
U
Sig+
B3
White/black
U
Sig–
B5
2
Pair 1
Red/white
U
Exc+
A7
Red/blue
U
Exc–
A8
Pair 2
Yellow/red
U
Sen+
B8
Yellow/blue
U
Sen–
A9
Pair 3
Grey/red
U
Sig+
B7
Grey/blue
U
Sig–
B9
