Revision B 120 Series Maternal/Fetal Monitor 8-7
2015590-001
Self-Tests: Error Log Screen
80 6894 Channel A communications error—J111
81 6894 Channel B communications error— FSpO
2
82 6894 Channel C communications error—MSpO2
83 6894 Channel D communications error—NBP
84–89 Reserved for future use
90 DSP communications watchdog timer
91 DSP Error 1—CRC on program in flash ROM is bad
92 DSP Error 2—A/D converter conversion time test failed
93 Unused
94 DSP Error 4—Run time RAM test failed
95 DSP Error 5—Power up test program sequence failed
96 DSP Error 6—Power up program RAM test failed
97 DSP Error 7—Power up data RAM test failed
98 DSP Error 8—Run time CPU utilization exceeded 100%
99 DSP Error 9—Supply voltages, voltage reference, or A/D invalid
100 DSP Error 10—DSP–MAIN data queue nearly full
101 DSP Error—DSP–MAIN data queue full; data is being lost
102 DSP Error—Power supply warning
103 DSP warm start
104 DSP—reserved for future use
105 DSP—reserved for future use
106 DSP—reserved for future use
107 DSP—reserved for future use
108 DSP—reserved for future use
109 DSP—reserved for future use
110 CPU requests for DSP packet re-transmission
111 Erroneous packets received from DSP
112–119 Reserved for future use
120 CAS Error 0—No error
121 CAS Error 1—Unused
122 CAS Error 2—Self-test failed
Table 8-1. Error Codes (Continued)
Error # Description
