GE Corometrics 126

12-36 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Upgrading a 120 Series Monitor: Software Version 3.5
Figure 12-29. Top View
J5
A
MATER
Sp
FECG/M
U
US
U
J6
J4
J10
J1
J7
J2
J1
J2
J9
J1
Notch in
DSP Board
BP Board
Display Cable
Membrane Switch
Panel Cable
Nipples for
BP Tubing
Recorder
Cavity Divider
