Revision B 120 Series Maternal/Fetal Monitor 12-37
2015590-001
Upgrading a 120 Series Monitor: Software Version 3.5
Figure 12-30. DSP Board
J5
Display Connector
J4
U8
U9
Membrane Switch
Panel Connector
Flash ROMs
