3-16 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Controls, Indicators, and Connectors: Front Panel Displays
Figure 3-12. Maternal Vital Signs History Screen Softkeys
Table 3-12. Maternal Vital Signs History Screen Softkeys
Name Description
A PRINT Softkey Prints one page (screen) of the table.
B PRINTALL Softkey Prints all pages (screens).
C VIEW Softkey
Scrolls through the data:
Left for recent data
Right for oldest data
D EXIT Softkey Returns to the previous screen.
DCBA
