Job Card TSG A015 - Lift Movement Troubleshooting
Page no. 1043 Chapter 9
JC-TSG-A-015.fm
ILLUSTRATION 3 - TROUBLESHOOTING FLOWCHART FOR LIFT MOVEMENT PROBLEMS RELATED TO
ERRORS 102/013 AND 102/014 - TYPE 1 LIFT SCREW ASSEMBLY
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
NOK
Grease Checks
See
section 3-2, Grease
Checks
on page 1048.
Grease Lift Screw
See
section 3-3, Grease Lift
Screw
on page 1049.
NOK
OK
NOK
Lift Gas Spring Checks
See
section 3-4, Lift Gas Spring
Checks
on page 1052.
NOK
Change Lift Gas Spring
See
Job Card D/R A206A - Lift
Gas Spring
on page 1183.
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
OK
Contact OLC.
Corrective actions
Change Lift Board
See
Job Card D/R A201 - Lift
Board
on page 1161.
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
NOK
Change the Lift Screw Assem-
bly with Motor (5391083 +
5212900)
See
Job Card D/R A232 - Lift
Screw Assembly
on page 1255.
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
