GE Senographe DS User Manual

Chapter 9 Page no. 1044
JC-TSG-A-015.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card TSG A015 - Lift Movement Troubleshooting
2-2 Trouble Shooting Steering Guide For Type 2 Lift Screw Assembly
Use the following flow charts (illustration 4 and illustration 5) to isolate the issue causing the Lift move-
ment problems on systems with a Type 2 Lift Screw Assembly.
ILLUSTRATION 4 - LIFT TROUBLESHOOTING ENTRY - TYPE 2 LIFT SCREW ASSEMBLY
Does customer complain about
Error 102/024 or does Error 102/024 repeatly
appear in the error logs?
Perform the lift trouble shooting steps described
in illustration 5,
Troubleshooting Flowchart For
Lift Movement Problems Related to Errors 102/
013 and 102/014 - Type 2 Lift Screw Assembly
on page 1045
Are Errors 102/013 and 102/014 present on a
weekly basis?
Proceed to the Grease Checks in illustration 5,
and follow the flowchart as required.
OK
NOK
Lift Gas Spring Checks
See
section 3-4, Lift Gas Spring
Checks
on page 1052.
NOK
Change Lift Gas Spring
See
Job Card D/R A206A - Lift
Gas Spring
on page 1183.
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048. After the
checks, return back here.
OK
OK
OK
OK
OK
NOK
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048.
OK
Contact OLC.
No
Yes
Yes
No
Install/change Top Brake
(5198687) - See
Job Card D/R
A233 - Lift Screw Assembly Top
Brake
Requires the old system to have
2373567-8 Lift Board and Lift
CPLD version 10.0.1 or above
Perform Lift Functional Checks.
See
section 3-1, Lift Functional
Checks
on page 1048. After the
checks, return back here.
OK
Install Type 3 Lift Screw Assembly with Brake Motor (5337148)
See
Job Card D/R A232 - Lift Screw Assembly on page 1255
Note: The brake functionality requires the old system to have
2373567-8 Lift Board and Lift CPLD version 10.0.1 or above. Check
the Service Desktop home page and if the Lift Board CPLD version
is less than 10.0.1 you must also change the Lift Board according to
Job Card D/R A201 - Lift Board on page 1161.
