Chapter 6 Page no. 506
JC-PHY-A-040.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
Job Card PHY A040 - Remove/Reinstall Control Station Covers
the radiation screen.
8. If the radiation screen is present, tighten with moderation the two screws (8).
9. Repeat steps 2 to 4 and 6 to 8 for the Omega cover on the other side of the Control Station.
10. Disconnect the ground cable from the right-hand side of the Omega cover.
8
7
