GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
Page no. 883 Chapter 9
ERR-SUB-A-003.fm
122/009 HALT LIFT UP BUTTON
STILL PRESSED
SwitchDefect [i] (for i = 1 - 11) occurs when the two
signals from the button do not arrive at the same
time on the CPLD.
The error signal indicates the nature of the button but
not the side right or left.
- Lift up (V1, V2)
- Lift down (V1, V2)
- Rotation Right (V1, V2)
- Rotation Left (V1, V2)
- Preset CC
- Preset +MLO
- Preset -MLO
See JC DIAG A1201 KEYPAD FAILURE on page
956 to fix the problem.
A1201
page 956
122/010 HALT LIFT UP BUTTON
STILL PRESSED
122/011 HALT LIFT DOWN BUT-
TON STILL
PRESSED
122/012 HALT LIFT DOWN BUT-
TON STILL
PRESSED
122/013 HALT ROTATION BUT-
TON STILL
PRESSED
122/014 HALT ROTATION BUT-
TON STILL
PRESSED
122/015 HALT ROTATION BUT-
TON STILL
PRESSED
122/016 HALT ROTATION BUT-
TON STILL
PRESSED
122/017 HALT CC BUTTON STILL
PRESSED
122/018 HALT +MLO BUTTON
STILL PRESSED
122/019 HALT -MLO BUTTON
STILL PRESSED
122/020 HALT COMPR BRAKES
LOW CURRENT
There is low brake current. Screwbrake brakes when
no current in it. Manual compression brake brakes
when supplied with current. The two brakes are sup-
plied from the same point and one of them brakes at
least all the time. In case the current that goes to the
two brakes falls below an acceptable limit, this signal
is sent.
See JC DIAG A1212 COMPRESSION BRAKE FAIL-
URE on page 960 to fix the problem.
A1212
page 960
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
