Chapter 9 Page no. 908
ERR-SUB-A-003.fm
GE Healthcare Senographe DS
Revision 1 Service Information and Procedures Class A 2385072-16-8EN
ERR SUB A003 - Gantry Error Messages
152/021 DEBUG
ONLY
PDU MCU reseted
while System is ON
The PDU MCU was reset while the system was on.
Ignore this error. If the error persists, contact your
OLC.
152/022 DEBUG
ONLY
A/D converter mod-
ule error on PDU
board
The A/D converter on the PDU board (U13) is bad
and the measurements are invalid.
Ignore this error. If the error persists, contact your
OLC.
152/023 DEBUG
ONLY
Diagnostic channel
selection circuit fail-
ure
PDU internal error
Ignore this error. If the error persists, contact your
OLC.
152/024 DEBUG
ONLY
Internal software
error
There has been an internal error with the PDU soft-
ware.
Ignore this error. If the error persists, contact your
OLC.
152/025 DEBUG
ONLY
Temperature is too
high or too low
The MPCB box temperature is out of the specified
+9 to +60 degrees operating range.
Ignore this error. If the error persists, contact your
OLC.
152/026 HALT Low power 2 fuse
failure
The low power 2 fuse (F1) to the nodes is faulty.
See JC DIAG A1504 LOW POWER 2 FUSE IS BAD
on page 975 to fix the problem.
A1504
page 975
152/027 HALT High power fuse fail-
ure
The high power fuse (F2) to the motors is faulty.
See JC DIAG A1505 HIGH POWER FUSE IS BAD
on page 975 to fix the problem.
A1505
page 975
152/028 HALT Low power 1 fuse
failure
The low power 1 fuse (F3) to the nodes is faulty.
See JC DIAG A1506 LOW POWER 1 FUSE IS BAD
on page 975 to fix the problem.
A1506
page 975
152/029 DEBUG
ONLY
CPU fuse failure The CPU fuse (F4) is faulty.
See JC DIAG A1507 MAIN CPU FUSE IS BAD on
page 975 to fix the problem.
A1507
page 975
152/030 HALT Generator on off
relay failure
Generator on/off switch relay (or its driver) is faulty.
The relay that turns off the Generator at shutdown
has over/under current on its drive coil.
Check the following relays:
Relay-X1 16 A
Relay-K1 K2 8 A
Relay-18A 230 V
Code Category Text in Log File or
on LCD
Possible Cause/Recommended Action Job Card
