GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 5 - Components and Functions (Theory) 5-33
5-4-1 Hard Disk Drive
The Hard Disk is the main storage device of the Voluson E8 / Voluson E6 ultrasound system.
The Voluson E8 / Voluson E6 Hard disk drive is divided into 4 partitions.
For further details see: Section 5-2-6 "Data Location" on page 5-23.
5-4-2 PC-Motherboard
5-4-2-1 KONTRON Dual-core or DFI Dual-core
Built in or external Components:
- On Board VGA
-LAN
- USB 2.0
- Sound
- CPU: 2133 MHz Dual
Major Tasks:
- System Control
- 2D- / 3D- / 4D- Image processing and Rendering
- Control DVD drive (USB)
- Control User Interface (USB)
5-4-3 ADD2-DVI (Add-On) Graphic Adapter Card
DVI graphic extension card which supplies RTV (Video manager) board with DVI Video.
BT Version:
The ADD2-DVI (Add-On) Card is only used at Voluson E6 (BT09/B10) systems.
