GE HEALTHCAREDRAFT VOLUSON E8 / VOLUSON E6
D
IRECTION KTD102576, REVISION 7 DRAFT (AUGUST 23, 2012) SERVICE MANUAL
Chapter 6 - Service Adjustments 6-1
Chapter 6
Service Adjustments
Section 6-1
Overview
6-1-1 Purpose of this Chapter
This chapter describes how to test and adjust the mechanical capabilities of a scanner that may be out
of specification. Although some tests may be optional they should only be performed by qualified
personnel.
6-1-2 Contents of this Chapter
6-1 Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-2 Regulatory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-3 LCD Monitor Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
6-4 Monitor Arm Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-6
6-5 Control Console Positioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-7
6-6 Modification of Keyboard Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-9
Section 6-2
Regulatory
Verify, where applicable, that any regulatory information or tests required by national law are present
and accounted for, and any regulatory tests required by national law are performed and documented.
Section 6-3
LCD Monitor Adjustment
The Voluson E8 / Voluson E6 has a free adjustable LCD monitor in relation to the user interface.
• position up/down: +/- 5 cm
• position left/right: +/- 20 cm
• rotation up/down: 30°/10°
• rotation left/right: +/- 45°
