104
5.3 Other Settings
5.3.1 Web Setting Switch
When the Web Setting switch is set to the ON position, you can modify Advanced Settings
and Extended Reader settings of GV-AS410 / 4110 / 810 / 8110 through its Web interfaces.
When the switch is set to the OFF position, Advanced Settings and Extended Reader
settings are not accessible. For details on Advanced Settings and Extended Reader settings,
see 8.2 Advanced Settings and 8.3.1 Extended Reader.
Figure 5-9
5.3.2 Resetting the GV-AS410 / 4110 / 810 / 8110
To reset GV-AS410 / 4110 / 810 / 8110, press the Reset button on the right side of GV-
AS410 / 4110 / 810 / 8110 circuit board for three seconds.
Ethernet
OUT21
OUT22
OUT24
OUT23
J14
Reset
Button
GND
IN16
IN15
GND
IN14
IN13
GND
IN12
IN11
GND
IN10
IN09
Figure 5-10
