Optional Devices
201
9
9.3.2.F In/Out Function
In the left menu, click In/Out Function to define the input and output sensors.
Figure 9-23
[Input Function]
Here you can define each sensor input that is connected GV-ASBox and select the most
fitting Input Type (No. 3, Figure 9-24) and Input Function (No. 4, Figure 9-24) to describe
the sensor input. Through the sensor input, an alarm event can be detected and it can then
trigger the alarm device.
Figure 9-24
Note: The I/O Configuration page is only available when connecting through a GV-ASBox.
1
2
3 4
To Next Page
