8
1.2.1 Connecting Card Readers
1.2.1.A Wiegand Readers (GV-AS100 Only)
GV-AS100 provides one Wiegand input for connection of the Wiegand reader ranging from
26 to 64 bits. Through the GV-AS100 keypad, you can set the Wiegand reader as the entry
or exit reader. To define the reader, see the AS100 Function option in 1.3.5 Setting
Parameters.
Note: Wiegand connection is not supported for GV-AS1010.
The table below shows the pin assignments of the Wiegand input on GV-AS100. Please
consult the documentation of your Wiegand reader for wiring.
Pin Function
7 Wiegand Data 0
8 Wiegand Data 1
9 12V Power Supply
10 GND
