GeoVision GV-AS1010 User Manual

32
1.5 GV-AS100 / 1010 Specifications
GV-AS100
CPU 8-bit RISC microprocessor
Number of User Cards
1,000 / 40,000 cards (standalone / networked or RS-
485 mode)
Frequency
13.56 MHz for ISO14443A (Mifare DESFire, Mifare
Plus and Mifare Classic)
Event Buffer 65,536 events and log data
Power 12V DC, 1A
1 Wiegand interface, 26 ~ 64 bit format
Wiegand Interface
12V DC Power Supply, 200mA
RS-485 Interface
1 RS-485 interface only for 1 GV-Reader or GV-GF
Fingerprint Reader
Communication Protocol RS-485
Input 3 inputs, dry contact, NO / NC
Digital I/O
Output 2 outputs
Supported ID Format Built-in reader reads UID only
Operating Temperature 0 ~ 65°C / 32 ~ 149°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Dimensions (W X H X D) 96 x 137 x 27 mm / 3.78 x 5.39 x 1.06 in
Weight 250 g / 0.55 lb
Ingress Protection IP54
Certification CE, FCC, RoHS
