GeoVision GV-AS1010 User Manual

Optional Devices
181
9
9.1.5 GV-ASBox Specifications
CPU 32-bit ARM7TDMI Microprocessor
Power 100 ~ 240V AC, 50 ~ 60 Hz
Battery 12V, 5Ah
RS-485 Interface
2 separate interfaces for GV-Readers and GV-
GF Fingerprint Readers (Max. 4 readers)
1 Wiegand interface, 26 ~ 64 bit format
Wiegand Interface
12V DC Power Supply, 200mA
GV-AS100/110/120 RS-485
Communication
Protocol
GV-ASManager TCP/IP (10/100 Mbps Ethernet)
Input 8 inputs, dry contact, NO / NC
Digital I/O
Output 8 outputs
Operating Temperature 0 ~ 65°C / 32 ~ 149°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Board Dimensions (W X H X D)
214 x 206 x 48.5 mm / 8.43 x 8.11 x 1.91 in
Weight 850 g / 1.83 lb
Certification CE, FCC, RoHS
All specifications are subject to change without notice.
