112
5.6 GV-AS410 / 4110 / 810 / 8110 Specifications
GV-AS410 / GV-AS4110
Control Mode
GV-AS410 GV-AS4110
One-Way Control 4 doors
Two-Way Control 4 doors by Wigand, RS-485 and Network
CPU 32-bit ARM7TDMI
Number of User Cards 40,000 cards
Event Buffer 1,000,000 events and log data
Power 12V DC, 3.5A
1 RS-485 interface
Up to 8 GV-Readers and GV-GF Fingerprint Readers
RS-485 Interface
Distance 600 m (1968.50 ft), 24 AWG
8 Wiegand interfaces, 26 ~ 64 bit format
Distance 30 m (98.43 ft), 24
AWG
Distance 100 m (328.1), 24
AWG
Wiegand Interface
12V DC power supply, 200mA
TCP/IP Interface 1 TCP/IP interface for GeoVision network readers
Communication Protocol TCP/IP
Battery Built-in battery Replaceable button cell
Input 16 inputs, dry contact, NO/NC
Output
24 relay outputs (30V DC, 3A; 110 ~ 250V AC, 3A)
Operating Temperature 0 ~ 65°C / 32 ~ 149°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Dimensions (W X H X D) 210 x 187 x 40 mm / 8.27 x 7.36 x 1.57 in
Weight 900 g / 2 lb
Certification CE, FCC, RoHS
All specifications are subject to change without notice.
