GV-AS120 Controller
63
3
3.2 Installation
The wire assignment of the GV-AS120 cable data are
illustrat
ed below
.
Front
View
Rear
View
Figure 3-4
Wi
re
co
lo
r
Definition
Red 12V
Black G
ND
Green
W
ie
gand Data 0
W
hi
te
W
ie
gand Date 1
Blue RS485+
Light Blue
RS485-
Brown
IN CO
M (GND)
Yellow
Door Sensor IN1
LRed Button
IN2
Purple Door
COM
Orange Door
NC
Gray Door
NO
80
82
