GeoVision GV-AS1010 User Manual

42
2.2.2 Connecting Input Devices
GV-AS110 supports 3 types of inputs, while GV-AS1110 supports 2 types of inputs.
1. GV-AS110 / 1110: Sensor inputs, e.g. door status sensor
2. GV-AS110 / 1110: Button inputs, e.g. door opener
3. GV-AS110 only: Fire Sensor inputs, e.g. fire detector
All inputs are dry contact and can be configured as normally open (NO) or normally closed
(NC) through the keypad. The default value is NO. To change the input status, see the
Select Input Contact Type option in 2.3.2 Programming the GV-AS110 / 1110.
The tables below show the wire assignments of input connectors on GV-AS110 and GV-
AS1110.
GV-AS110
Wire color Definition
Yellow Door Sensor IN1
Orange Button IN2
LRed Fire Sensor IN3
Brown IN COM (GND)
GV-AS1110
Wire color Definition
Green IN COM (GND)
Blue Door Sensor IN1
Purple Button IN2
