The Web Interface
163
8
In the Output Condition settings, these Output Type and Output Condition become
available:
Output Condition Output Type
Door # Gate # Relay # Input/Reader
Access Granted Access Granted Access Granted
Access Denied Access Denied Access Denied
Fire Alarm Fire Alarm Fire Alarm
Tamper Tamper Tamper
Duress Event Duress Event Duress Event
Held Open Held Open
Forced Open Forced Open
Exit Button Exit Button
Normal
Toggle
Pulse
Door Contact Car Detection
Select None to
disable the
condition, or select
an Input, Wiegand,
or Reader to
trigger the output.
Click Reset button to return the Normal, Toggle or Pulse triggered state to be normal.
Click Submit button to save the changes, or click Cancel button to return the changes to its
previous state.
Note: The Reset button is more commonly used for the Toggle output because once
triggered, the output will go on forever. A Reset button is needed to turn it off.
