2.2 Screen Names and Configurations
32
Displays the ΔV10 statistics below in a
list.
• The maximum value over one hou
r
for ΔV10 Flicker
• The fourth maximum value over on
e
hour for ΔV10 Flicker
• The average value over one hour fo
r
ΔV10 Flicker
• Overall maximum value for
ΔV1
0
Flicker
The statistics are updated once an
hour.
This is only displayed if
Δ V10 is selec
t-
ed for flicker in [SYSTEM] - DF2
[MAIN] - [MEASURE]
.
LIST 6.6 "Flicker"(page 104)
FLICKER TIME PLOT Screen
Displays the IEC flicker (Pst, Plt) val-
ues in a list.
• Pst (short interval voltage flicker)
• Plt (long interval voltage flicker)
The list is updated every 10-minute.
This is only displayed if Plt, Pst is se-
lected for flicker in
[SYSTEM] - DF2
[MAIN] - [MEASURE].
Displays a list for IEC flicker or ΔV10 flicker
IEC Flicker
ΔV10 Flicker
Flicker analysis is not available when measuring 400 Hz.
