Servo Drive Configuration E1 Series Servo Drive Thunder Software Operation Manual
4-28 HIWIN MIKROSYSTEM CORP.
Figure 4.3.6.2.3
“Electronic gear ratio setting” window only supports standard servo drive, and it will display
different window based on encoder setting. Refer to the following table for the related information.
Table 4.3.6.2.3
Full-closed loop not activated
All mechanical structure’s electronic gear ratio setting (except for
linear motor and full-closed loop)
Full-closed loop activated
Full-closed loop’s electronic gear ratio setting
For the electronic gear ratio setting of Fieldbus servo drive’s EtherCAT model (ED1F-E□-□□□
□-□□), users have to modify Pt20E and Pt210 in Configuration Wizard.
