Honeywell SmartLine SLG 700 User Manual

Page 110 SLG 700 SmartLine Level Transmitter User’s Manual Revision 8
Backgrnd
Capture
(Measured
Prod not
Saturated
Steam)
Backgrnd Type
Field
Obstacle
Background type to capture.
Use Level
(Obstacle Backgrnd
Type only)
Yes
No
Use level instead of distance to
surface for Obstacle capture
length entered at time of capture.
Start Capture
(capture process is
inactive)
Begins a field background
capture process, with progress
indicated by bar graph on line
immediately above. For Obstacle
captures, an entry of the capture
length is required.
Press ↵ to
select
action
Cancel Capture
(capture process is
active)
Cancels the currently active field
background capture process.
Probe
Note: Loop
must be
removed from
Automatic
Control.
<Return>
Probe Type
Custom
Rod
Wire
Coax
Multi-twist
Wire
PTFE Rod
PTFE Wire
Type of probe.
Press  to
enter menu
selection
 and  to
select
number.
 to enter
and shift to
next digit
Probe Length
##.###
Length of the probe in the tank,
in Length units.
Probe End Type
None
Clamp
Weight
Loop
Type of probe end.
CenterDiskType
None
316 SS
PTFE
C276 Ni
Alloy
Type of centering disk
CenterDisk Dia
(If Center Disk Type is
not None)
2 inch to 8
inch
Diameter of centering disk
PropagtnFactor
#.######
Probe wave propagation factor
Block Dist Hi
#.###
Configures region near the
flange where measurements are
not possible and inaccurate.
Value entered is in Length units.
Block Dist Low
#.###
Configures region near the
Probe end where measurements
are not possible and inaccurate.
Value entered is in Length units.
SteamRefPrbTyp
(Saturated Steam
Measured Prod only)
None
30 cm
50 cm
Type of steam reference probe.
Steam Ref Len
(Saturated Steam
Measured Prod only)
##.###
Length of Steam Reference
Probe, in Length units.
