Honeywell SmartLine SLG 700 User Manual

Revision 8 SLG 700 SmartLine Level Transmitter User’s Manual Page 111
Probe
Length Cal
(SingleLiqLo
wDC
Measured
Prod only)
<Return>
Start Cal
(calibration process
is inactive)
Begins a probe length
calibration, with progress
indicated by bar graph on
line immediately above.
Press ↵ to
select action
Stop Cal
(calibration process
is inactive)
Cancels the currently
active probe length
calibration process.
Steam Ref
Cal
(Saturated
Steam
Measured
Prod only)
<Return>
Start Cal
(calibration process
is inactive)
Begins a steam reference
calibration, with progress
indicated by bar graph on
line immediately above.
Press ↵ to select
action
Stop Cal
(calibration process
is inactive)
Cancels the currently
active steam reference
calibration process.
Volume
<Return>
Vol Calc Type
None
Tank Shape
Strapping Table
Volume calculation type
Press  to enter
menu selection. 
and  to select
from list.  to
enter.
Tank Shape
Sphere
Cube
Horz Bullet
Vert Bullet
Vert Cylinder
Horz Cylinder
Rectangle
Visible only if Vol Calc Type
is Tank Shape.
Tank Diameter
###.###
Visible for Sphere, Bullet
and Cylinder Tank Shapes
only. Value entered is in
Length units.
Press  to enter
menu selection. 
and  to select
number.  to
enter and shift to
next digit
Tank Length
###.###
Visible for Cube, Rectangle,
Horz Bullet and Horz
Cylinder Tank Shapes only.
Value entered is in Length
units.
Tank Width
###.###
Visible for Rectangle Tank
Shape only. Value entered
is in Length units.
Tank Height
###.###
Visible for Vert Bullet and
Vert Cylinder Tank Shapes
only. Value entered is in
Length units.
Volume Offset
(Vol Calc Type is Tank
Shape only)
###.###
Offset value applied to the
calculated volume.
Visible only if Vol Calc Type
is Tank Shape.
