Clear Point
Function Group
POWER
Menu Map
5
Description
This softkey lets you change the correction value for the active
frequency point to the “Undefined” state.
Programming Codes
SCPI:
NONE,
see Fltness Menu
Analyzer: NONE
See
Also
(ALC),
Fltness
Menu
“Optimizing Swept CW Generator Performance”
in Chapter 1
CONNECTORS
BNC Connectors
AUX OUTPUT provides a reference signal from 2 to 26.5 GHz at a
typical minimum power level of -10
dBm.
Nominal input impedance
is 50
0.
EXT ALC allows the swept CW generator to be externally leveled.
This input is used for power meter leveling or negative crystal
detector leveling.
Input impedance in crystal or meter leveling modes is nominally
1
MSZ.
See “Specifications” for the signal requirements. Nominal
input impedance is 100 kR.
SWEEP OUTPUT
provides a voltage range of 0 to
+lO
V. When
the swept CW generator is sweeping, the SWEEP OUTPUT is
0 V at the beginning of the sweep and
+lO
V at the end of the
sweep regardless of the sweep width. In CW mode, the SWEEP
OUTPUT ranges from 0 V at the swept CW generator minimum
frequency to
+lO
V at the specified maximum frequency, with a
proportional voltage for frequencies between the specified minimum
and maximum. When the swept CW generator is in manual sweep
operation the sweep output voltage is a percentage of the span.
Minimum load impedance is 3 kR.
STOP SWEEP IN/OUT stops a sweep when this input is pulled
low.
Retrace does not occur, and the sweep resumes when this input is
pulled high.
C-4 Operating and Programming Reference
