Manual Operation
Compatibility
The HP 8360 L-Series swept CW generators are designed to be, in all
but very few cases, a complete feature superset of the HP 8340/8341
synthesized sweepers. The most notable omissions are that the
HP 8360 L-Series does not accept:
n line triggers (ie. 50 or 60 Hz line frequency)
n an external leveling input from positive diode detectors
Front Panel Operation
The HP 8360 L-Series uses a softkey menu driven approach toward
accessing instrument functions versus a front panel key or shift key
sequence as with the HP 8340/8341.
Instrument Preset Conditions. The factory defined preset conditions
for the HP 8360 L-Series are identical to those for the HP 8340/8341.
The HP 8360 L-Series also allows you to define a different set of
preset conditions. Refer to “Changing the Preset Parameters” in
Chapter 1 for examples and more information. Table 3-7 illustrates
the factory instrument preset conditions for the HP 8360 L-Series
and the HP 8340/8341. An instrument preset turns off all the
functions and then sets the following:
Table 3-7.
Instrument Preset Conditions for the HP 8380/8340/8341
Function
Condition
Sweep Mode
Full Span
Sweep
Continuous/Auto
Trigger
Free Run
Markers
All Off
Modulation
Off
Frequency Step Size
10% of span
Status Bvtes
Cleared
I Leveling
Internal
RF Output
Power Level
Power Step Size
Power Sweep/Slope
On
0 dBm
10 dB
0 dB
Storage Registers
Retain current values
HP-IB Address
Retains current value
Status Byte Mask
Unchanged
Extended Status Byte Mask Unchanged
Language Mode
Unchanged
3-20 Installation
