Auto Fill #Pts
Auto Fill
#Pts
Function Group
FREQUENCY, POWER
Menu Map
2,s
Description
This softkey is used in two locations:
Fitness
Menu and
List
Menu.
Flatness Menu
-
When selected, the swept CW generator waits for
a numeric value representing the number of correction points to be
entered.
-->
Number of Correction Points: is displayed in the
active entry area. A list of frequencies containing the number of
specified points is created automatically. The list begins at the auto
fill start frequency and ends at the auto fill stop frequency. The rest
of the points are equally spaced between them. A minimum of two
points must be entered.
If the number of points requested creates a list that exceeds the
number of elements available (801), the following message appears:
TOO MANY CORRECTION PTS REQUESTED
List Menu
-
When selected, the swept CW generator waits for a
numeric value representing the number of list points to be entered.
-->
Number of List Frequencies: is displayed in the active
entry area. A list of frequencies containing the number of specified
points is created automatically. The list begins at the auto fill start
frequency and ends at the auto fill stop frequency. The rest of the
points are equally spaced between them. A minimum of two points
must be entered.
If the number of points requested creates a list that exceeds the
number of points available (801), the following message appears:
list points requested.
Error. . .too many
Points used: 0
Points available
: 801
Programming Codes
SCPI: NONE, see Fltness Menu or List Menu
Analyzer: NONE
See Also
Fltness Menu, List Menu
“Optimizing Swept CW Generator Performance” in Chapter 1
Operating and Programming Reference A-19
