[MARKER)
Function Group
MENU SELECT
Menu Map
3
Description
This
hardkey
allows access to the marker functions.
Amp1
Markers
Center=Marker
Causes the swept CW generator to display
markers as an amplitude pulse.
Changes the swept CW generator’s center
frequency to the value of the most recently
activated marker.
Delta Marker
Delta Mkr Ref
Displays the frequency difference between the
active marker and the marker designated by the
softkey
Delta Mkr
Ref .
Reveals the softkeys in the delta marker
reference menu.
MI--M2 Sweep
Causes the swept CW generator to sweep from
Ml to M2.
Marker Ml
Marker M2
Marker M3
Marker M4
Marker
M5
Markers All Off
Start=Ml
Stop=MZ
Makes Ml frequency the active function.
Makes M2 frequency the active function.
Makes M3 frequency the active function.
Makes M4 frequency the active function.
Makes M5 frequency the active function.
Turns off all markers.
Changes the swept CW generator start and stop
frequencies to the values of Ml and M2.
The markers are functional whenever an asterisk appears next to the
key label, but only one marker can be active at a time. The active
marker is indicated in the active entry area.
See Also
Softkeys listed above.
“Marker Operation” in Chapter 1
“Programming Typical Measurements” in Chapter 1
Operating and Programming Reference M-3
To Next Page
